Gold Separation Method

Processing ability: 0.2–16 m³/min

Impeller rotation speed: 191–400 r/min

Dimensions: 700×700×750–2200×2900×1400 mm

Applied material: non-ferrous metals, ferrous metals, precious metals, non-metallic mineral, chemical raw materials, etc

  • Photo
  • video

The Application and Description of Gold Separation Method:

The gold separation method is applicable for separating non-ferrous metal, black metal, noble metal, non-metal mineral, raw body and materials of chemical industry, which are subject to coarse separation, swept separation and flotation, so the useful ore are reclaimed.

flotation

The Performance Characteristics of Gold Separation Method:

1. Large inhaling capacity and low consumption.

2. Complete flotation circuit with inhaling air and slurry, no auxiliares are needed.

3. Process is easy to be changed.

4. Reasonable circulation of slurry decreases coarse sand sedimentation.

flotation

Before starting the machine, first check the bolts of all spare parts and before stopping the machine, manually spin the wheel to prevent the depositing of sediment from increasing the load of electro motor. During the working process, carefully adjust the height of the flashboard to maintain the stability of the liquid level, so that the mineralized bubbles on the liquid surface of the pump can be timely scraped to the launder. A certain space should be maintained between the impeller and the stator, and when the impeller is abraded, it should be changed timely, and the bearing inside the pump should be maintained every three month.

Mix the mashed rocks with water and necessary reagent in the mixing chute, and inject them to the pulp chute. Lead air to the pulp to make it form large quantities of bubbles, and some mineral particles that are difficult to get moist in water and that are generally called hydrophobic mineral particles will stick on the bubbles and float with the bubbles to the surface of the pulp to form mineralized bubble layer, and some other mineral particles that are easy to get moist in water and that are called hydrophilic mineral particles do not stick on the bubbles but stay in the pulp to discharge the mineralized bubbles containing specific minerals, thus completing the separation process.

Technical data

Category Specification
Model
Effective
cubage
(m³)
Processing
capacity
(m³/min)
Main shaft     loam board Dimensions
(L×W×H)
(mm)
Single
 trough
Weight
(kg)
Power
(kw)
Rotate
speed
(r/min)
Rotate
 speed
(r/min)
Power
(kw)
XJK type
flotation
machine
XJK-0.35 0.35 0.18-0.4 1.5 483 25 1.1 700×700×700 460
XJK-0.62 0.62 0.3-0.9 3.0 400 25 1.1 900×820×850 980
XJK-1.1 1.1 0.6-1.6 5.5 330 25 1.1 1100×1100×1000 1390
XJK-2.8 2.8 1.5-3.5 11 280 25 1.1 1750×1600×1100 2430
XJK-5.8 5.8 5-7 22 240 25 1.5 2200×2200×1200 3533
SF type
flotation
machine
SF-0.37 0.37 0.2-0.4 1.5 386 25 1.1 700×700×750 468
SF-0.7 0.7 0.3-0.9 3 400 25 1.1 900×820×950 990
SF-1.2 1.2 0.6-1.6 5.5 330 25 1.1 1100×1100×1100 1873
SF-2.8 2.8 1.5-3.5 11 268 25 1.1 1750×1600×1150 2538
SF-4 4 2-4 15 220 25 1.5 1850×2050×1200 2838
SF-8 8 4-8 30 191 25 1.5 2200×2900×1400 4129
SF-10 10 5-10 30 191 25 1.5 2200×2900×1700 4486
SF-20 20 5-20 30×2 191 25 1.5 2850×3800×2000 9828
JJF type
 flotation
machine
JJF-2 2 1-3 7.5 443 25 1.5 1400×1400×1100 1670
JJF-4 4 2-4 11 305 25 1.5 1600×2150×1250 2350
JJF-8 8 4-8 22 233 25 1.5 2200×2900×1400 4500
JJF-10 10 5-10 22 233 25 1.5 2200×2900×1700 4820
JJF-16 16 5-16 30 180 25 1.5 2850×3800×1700 8000
JJF-20 20 5-20 37 180 25 1.5 2850×3800×2000 10500
