Rotary Kiln

Specification: Φ2.5×40m-Φ6.0×95(m)

Processing capacity: 180-1000(t/d)

Applied material: dolomite, active lime, cement clinker, and bauxite.

Applied area: portland cement making industry.

  • Photo
  • video

The Main Types and Description of Rotary Kiln:

Rotary kiln refers to rotary calcining kiln which belongs to building material equipment. According to the material types to be processed, rotary kiln can be divided into cement kiln, metallurgical chemistry kiln and limestone kiln.

Rotary Kiln

The Concrete Category and Function of Rotary Kiln:

Cement kiln is mainly used for calcining the cement clinker and it can be divided into dry-producing cement kiln and wet-producing cement kiln. Metallurgical chemistry kiln is mainly used for the magnetizing roasting of the lean iron ore and the oxidizing roasting of the chromium and josephinite in the steel works in the metallurgical industry, for the roasting of high alumina bauxite ore in the refractory plant, for the roasting of clinker and aluminium hydroxide in the aluminium manufacturing plant and for the roasting of chrome ore in the chemical plant. Limestone kiln is mainly used for roasting active lime and lightly calcined dolomite used in the steel works and ferroalloy works.

rotary_kiln

Feature:Save pulverized coal, Harmless, Fuel use

No.

Technical data

Product
Specification
(m)
Kiln dimensions Motor
power
(kw)
Total
weight
(t)
note
Diameter
(m)
Length
(m)
Obliquity
(%)
Capacity
(t/d)
Rotation
speed
(r/min)
Φ2.5×40 3.2 50 4 1000 0.6-3 125 278

-----

Φ2.5×50 3 60 3.5 300 0.3-2 100 310 -----
Φ2.5×54 3 48 3.5 700 0.6-3.48 100 237

outside

disassemble

kiln

Φ2.7×42 3 45 3.5 500 0.5-2.47 75 210.94 ------
Φ2.8×44 2.8 44 3.5 400 0.437-2.18 55 201.58

outside

disassemble

kiln

Φ3.0×45 2.7 42 3.5 320 0.10-1.52 55 198.5 ------
Φ3.0×48 2.5 54 3.5 204 0.48-1.45 55 196.29

outside

disassemble

klin

Φ3.0×60 2.5 50 3 200 0.62-1.86 55 187.37 ------
Φ3.2×50 2.5 40 3.5 180 0.44-2.44 55 149.61

outside

disassemble

klin

Φ3.3×52 3.3 52 3.5 1300 0.266-2.66 125 283

kiln with

preheater

precalcine

Φ3.5×54 3.5 54 3.5 1500 0.55-3.4 220 363

kiln with

prehrater

precalcine

Φ3.6×70 3.6 70 3.5 1800 0.25-1.25 125 419

Generating

klin for

usimg ofterheat

Φ4.0×56 4 56 4 2300 0.41-4.07 315 456

klin with

prehrater

precalcine

Φ4.0×60 4 60 3.5 2500 0.396-3.96 315 510

klin with

prehrater

precalcine

Φ4.2×60 4.2 60 4 2750 0.41-4.07 375 633

klin with

prehrater

precalcine

Φ4.3×60 4.3 60 3.5 3200 0.396-3.96 375 583

klin with

prehrater

precalcine

Φ4.5×66 4.5 66 3.5 4000 0.41-4.1 560 710.4

klin with

prehrater

precalcine

Φ4.7×74 4.7 74 4 4500 0.35-4 630 849

klin with

prehrater

precalcine

Φ4.8×74 4.8 74 4 5000 0.396-3.96 630 899

klin with

prehrater

precalcine

Φ5.0×74 5 74 4 6000 0.35-4 710 944

klin with

prehrater

precalcine

Φ5.6×87 5.6 87 4 8000 Max4.23 800 1265

klin with

prehrater

precalcine

Φ6.0×95 6 95 4 10000 Max5 950×2 1659

klin with

prehrater

precalcine
